Stock No: 356390 Enquire about this vehicle Enquire via
LINDE REACH
££ Login to see price Register for a trade account Model R16HD-01 1120
Year 2013
Euromast 3F700
Hours 3660
Capacity 1600 kg
Lift height 7000
Download
Share
Further Vehicle Details
Specification:
Type REACH
Make LINDE
Valves
Character.
Load Centre (c) 400-600 mm
Operating mode (Characteristic) Seated
Weights
Service weight (Total weight ) 3980 kg
Wheels
Tyres type Polyurethane
Dimensions
Free lift (h2) 2400 mm
Lift height (h3) 7000 mm
Extended height (h4) 7820 mm
Height of overhead guard (cabin) (h6) 2090 mm
Height of reach legs (h8) 310 mm
Overall length (l1) 2450 mm
Length to fork face (l2) 1250 mm
Overall width (b1/b2) 1275 mm
Forks length (l) 1200 mm
Fork carriage (class) DIN 15173 / 2A
Fork carriage width (b3) 870 mm
Width between legs (b4) 910 mm
Reach travel (l4) 465 mm
Collapsed height (h1) 2920 mm
Forks height (s) 45 mm
Forks width (e) 100 mm
Performance
Service brake electromagnetic
Drive
Battery weight 1175 kg
Drive motor (60 min rating) 6.5 kW
Lift motor (15% rating) 12 kW
Battery class British Standard
Battery voltage/capacity 48V / 775Ah V/Ah
Battery (Acc. to DIN) HOPPECKE
Attachment
Attachments (Has attachment) Sideshift and Forks.
Attachment type (Attachment type) Sideshifts
Engine
Engine type (Engine type) electric
Extras
Extras SS.
Extras Hyds 3rd & 4th
Battery
Battery Serial No 252461
Battery Year (Battery Year of Manufacture) 2013
