JUNGHEINRICH STACKER, WRAPOVER
STACKER, WRAPOVER • Stock No: 485803 £
Login to see price Model EJC 214 RENTAL
Year 2018
Euromast 3F535
Hours 2108
Capacity 1400 kg
Lift height 5350
Back to search results
![JUNGHEINRICH STACKER, WRAPOVER]()
![JUNGHEINRICH STACKER, WRAPOVER]()
![JUNGHEINRICH STACKER, WRAPOVER]()
![JUNGHEINRICH STACKER, WRAPOVER]()
![JUNGHEINRICH STACKER, WRAPOVER]()
Stock No: 480891 Enquire about this vehicle Enquire via
JUNGHEINRICH STACKER, WRAPOVER
£ Login to see price Register for a trade account Model EJC 214 RENTAL
Year 2018
Euromast 3F535
Hours 2243
Capacity 1400 kg
Lift height 5350
Download
Share
Further Vehicle Details
Specification:
Type STACKER, WRAPOVER
Make JUNGHEINRICH
Valves
Character.
Load Centre (c) 500/600/700 mm
Operating mode (Characteristic) Pedestrian
Load distance (x) 687 mm
Weights
Service weight (Total weight ) 1200 kg
Wheels
Tyre size front 85 x 110 mm
Tyre size rear 260 x 70 mm
Track width front (b10) 510 mm
Track width rear (b11) 375 mm
Dimensions
Lift height (h3) 5350 mm
Extended height (h4) 5730 mm
Overall length (l1) 2000 mm
Length to fork face (l2) 850 mm
Overall width (b1/b2) 810 mm
Forks length (l) 1150 mm
Fork spread (min/max) (b5) 580 mm
Width between legs (b4) 200 mm
Ground clearance, centre of wheelbase (m2) 30 mm
Turning radius (Wa) 1488 mm
Collapsed height (h1) 2250 mm
Forks height (s) 60 mm
Forks width (e) 190 mm
Auxiliary lift (h9) 1860 mm
Performance
Service brake electromagnetic
Drive
Battery weight 202 kg
Drive motor (60 min rating) 1,6 kW
Battery class British Standard
Battery voltage/capacity 24V / 225Ah V/Ah
Battery (Acc. to DIN) JUNGHEINRICH
Attachment
Attachments (Has attachment) Forks.
Attachment type (Attachment type) Forks
Engine
Engine type (Engine type) electric
Extras
Extras 1150x580, Built-in Charger
Battery
Battery Serial No C81093086
Battery Condition (Battery Condition) VERY GOOD %
Battery Year (Battery Year of Manufacture) 2018
