JUNGHEINRICH REACH
REACH • Stock No: 484028 £££
Login to see price Model ETV325
Year 2015
Euromast 3F1202
Hours 6103
Capacity 2500 kg
Lift height 12020
Back to search results
![JUNGHEINRICH REACH]()
![JUNGHEINRICH REACH]()
![JUNGHEINRICH REACH]()
![JUNGHEINRICH REACH]()
![JUNGHEINRICH REACH]()
Stock No: 455188 Enquire about this vehicle Enquire via
JUNGHEINRICH REACH
££ Login to see price Register for a trade account Model ETV318
Year 2015
Euromast 3F911
Hours 7485
Capacity 2500 kg
Lift height 9110
Download
Share
Further Vehicle Details
Specification:
Type REACH
Make JUNGHEINRICH
Valves
Character.
Load Centre (c) 500 mm
Operating mode (Characteristic) Seated
Weights
Service weight (Total weight ) 4213 kg
Wheels
Tyres type Polyurethane
Dimensions
Lift height (h3) 9110 mm
Extended height (h4) 10105 mm
Height of overhead guard (cabin) (h6) 2175 mm
Height of reach legs (h8) 290 mm
Overall length (l1) 2430 mm
Length to fork face (l2) 1430 mm
Overall width (b1/b2) 1275 mm
Forks length (l) 1000 mm
Fork carriage (class) DIN 15173 / 2A
Fork carriage width (b3) 855 mm
Width between legs (b4) 940 mm
Length of chasis (l7) 1820 mm
Collapsed height (h1) 4250 mm
Forks height (s) 40 mm
Forks width (e) 120 mm
Performance
Service brake electromagnetic
Drive
Battery weight 1175 kg
Drive motor (60 min rating) 6,9 kW
Battery class British Standard
Battery voltage/capacity 48V / 775Ah V/Ah
Battery (Acc. to DIN) MIDAC / JUNGHEINRICH
Attachment
Attachments (Has attachment) Sideshift and Forks.
Attachment type (Attachment type) Sideshifts
Engine
Engine type (Engine type) electric
Extras
Extras SS.
Extras Hyds 3rd & 4th
Battery
Battery Year (Battery Year of Manufacture) 2015
