EP STACKER, WRAPOVER
STACKER, WRAPOVER • Stock No: 681722 £
Login to see price Model ESL122 80
Year 2023
Euromast 2W360
Hours 1
Capacity 1200 kg
Back to search results
Stock No: 685452 Enquire about this vehicle Enquire via
EP STACKER, WRAPOVER
£ Login to see price Register for a trade account Model ESL122 80 RENTAL
Year 2023
Euromast 2W300
Hours 0
Capacity 1200 kg
Lift height 3000
Download
Share
Further Vehicle Details
Specification:
Type STACKER, WRAPOVER
Make EP
Valves
Character.
Load Centre (c) 600 mm
Operating mode (Characteristic) Pedestrian
Wheelbase (y) 1212 mm
Load distance (x) 798 mm
Weights
Service weight (Total weight ) 593 kg
Wheels
Tyre size front 210×70 mm
Tyre size rear 74x72 mm
Track width front (b10) 531 mm
Track width rear (b11) 405 mm
Dimensions
Lift height (h3) 3000 mm
Extended height (h4) 3550 mm
Overall length (l1) 1710 mm
Length to fork face (l2) 560 mm
Overall width (b1/b2) 793 mm
Forks length (l) 1150 mm
Fork spread (min/max) (b5) 230 mm
Width between legs (b4) 300 mm
Collapsed height (h1) 2050 mm
Forks height (s) 60 mm
Forks width (e) 170 mm
Performance
Travel speed (With, w/o load) 4.2/4.5 km/h
Lifting speed (With, w/o load) 0.10/0.14 m/s
Lowering speed (With, w/o load) 0.10/0.10 m/s
Service brake electromagnetic
Drive
Charger Type 24V LITHIUM BUILT IN
Battery weight 26 kg
Drive motor (60 min rating) 0.75 kW
Lift motor (15% rating) 2.2 kW
Battery voltage/capacity 24V/80AH V/Ah
Battery (Acc. to DIN) LITHIUM
Engine
Engine type (Engine type) electric
Extras
Extras BUILT IN CHARGER.
Battery
Battery Year (Battery Year of Manufacture) 2022
