LINDE REACH
REACH • Stock No: 356928 £
Login to see price Model R16X 116
Year 2012
Euromast 3F970
Hours 5665
Capacity 1600 kg
Lift height 9700
Back to search results
![LINDE REACH]()
![LINDE REACH]()
![LINDE REACH]()
![LINDE REACH]()
![LINDE REACH]()
Stock No: 341214 Enquire about this vehicle Enquire via
LINDE REACH
£ Login to see price Register for a trade account Model R16 PYROBAN
Year 1998
Euromast 3F700
Hours 0
Capacity 1600 kg
Lift height 7000
Download
Share
Further Vehicle Details
Specification:
Type REACH
Make LINDE
Valves
Character.
Load Centre (c) 500/600 mm
Operating mode (Characteristic) Seated
Weights
Service weight (Total weight ) 3117 kg
Wheels
Tyres type Polyurethane
Dimensions
Free lift (h2) 2830 mm
Lift height (h3) 7000 mm
Extended height (h4) 8060 mm
Height of overhead guard (cabin) (h6) 2090 mm
Height of reach legs (h8) 310 mm
Overall length (l1) 2280 mm
Length to fork face (l2) 1310 mm
Overall width (b1/b2) 1250 mm
Forks length (l) 1000 mm
Fork carriage (class) DIN 15173 / 2A
Fork carriage width (b3) 865 mm
Width between legs (b4) 935 mm
Reach travel (l4) 445 mm
Length of chasis (l7) 1720 mm
Collapsed height (h1) 2910 mm
Forks width (e) 100 mm
Performance
Service brake electromagnetic
Drive
Battery weight 986 kg
Drive motor (60 min rating) 6,5 kW
Battery voltage/capacity 48V / 465Ah V/Ah
Attachment
Attachments (Has attachment) Sideshift and Forks.
Attachment type (Attachment type) Sideshifts
Engine
Engine type (Engine type) electric
Extras
Extras SS, PYROBAN, Stainless Steel Forks.
Extras Hyds 3rd & 4th
